The outstanding choice for studio reference playback, professional mastering & audiophile listening environments

The original ADI-2 Pro model is the brain-child of RME’s Head of Design Matthias Carstens, who designed it to be his own personal AD/DA converter and headphone amplifier (after he’d continually been disappointed other offerings on the market…).

An early prototype was shown at several trade shows around the world. Such was the positive feedback – with many passers-by asking “when’s it going to be available?” – the decision was made to release the device publicly, and the ADI-2 Pro quickly took the crown of RME’s best-sounding device to date.

The range has since been expanded into a selection of high-end recording and playback devices that cover a wide range of applications. Mastering engineers use the original ADI-2 Pro to handle front-end conversion duties, whilst Hi-Fi enthusiasts continue to be impressed by the ADI-2 DAC FS, for its combination of exquisite DA conversion and powerful headphone amplification.

With the entire product series built into compact half-rack 9.5” casings, each one packs a huge amount of features and I/O into a reference-class audio device that can easily slot into even the smallest of studios.

ADI-2 Pro FS R - Black Edition

RME’s reference AD/DA converter is an USB 2.0 DAC, interface and a high-end headphone amplifier. Its design, unique specifications, user features and its ability to deliver crystal transparency, make it perfect for mastering and measurement applications as well as the ultimate tool for audiophiles everywhere.

The ADI-2 boasts high-grade components and intelligent circuitry throughout its half rack design. With RME’s fresh concept in Plug & Play the comprehensive feature set is easy to set up and use. Based on current connections the ADI-2 Pro FS R will automatically switch to AD/DA converter, USB interface or analog preamp mode. A specific mode can be set if required.

The ADI-2 Pro FS R offers sample rates of up to 768 kHz for both AD (2) and DA (4) channels of conversion. The new ADI-2 Pro FS R Black Edition features the AK4493 chip, slightly improved specs and comes with the new extended Multi-Remote Control (MRC).

RME have incorporated many unique features, not found on any comparable devices, like 5-band parametric EQs for fully individual phones compensation, adjustable Bass/ Treble controls with quick access, a binaural crossfeed function, adjustable loudness filter, selectable AD/DA filters, four discrete I/O reference levels, auto reference level setting, auto balanced phones mode, and many more.

In a class of their own

A new experience in Sound and Quality with sample rates of up to 768 kHz. The ADI-2 Series boasts high-grade components and intelligent circuitry throughout its half rack design. With RME’s fresh concept in Plug & Play the comprehensive feature set is easy to set up and use.

Both the ADI-2 DAC FS and ADI-2 Pro FS R feature on-board DSP processing, enabling advanced features like applying corrective EQ to all outputs (including separately for left and right channels), and a re-designed version of the ‘Loudness’ function found on many traditional Hi-Fi devices.

While headphones open the sound stage and make everything easier to hear and to locate by spreading the narrow sound field of stereo speakers to the left/right extreme, some people would like to have a listening situation that is more comparable to a standard speaker setup.

The ADI-2 DAC FS and ADI-2 Pro FS R includes Crossfeed to address this wish. Crossfeed reduces the artificial surround ambience that some productions have to make them sound better on speakers, but which sounds unnatural on a headphone. It uses the Bauer Binaural method, with five selectable strengths of narrowing the upper frequencies. This advanced method, which also includes a small delay and correction of the frequency response, works quite well, and is another useful addition as well as a unique feature.

The Series features also a high-quality, high-power headphone output with very low output noise. This is based around the proven High Power output found on many of RME’s other products.
